Cutting tools vacuum coating machine can improve the cutting speed of the tool and reduce processing time and cost, longer service life reduces the tool replacement cost, coating has excellent thermal stability, hot hardness and antioxidant capacity, low friction coefficient and low adhesion tendency. Vacuum plating chamber, its vacuum sealing and indoor sports parts design and materials, full consideration can withstand high temperatures, configuration only, circular arc evaporation source, or with a plurality of rectangular plane arc evaporation source, also can be equipped with a plurality of hollow cathode gun, and impact resistance, has excellent arc flash properties of bias power supply, ensuring adequate plasma density and reaction activity, the film density and the binding force improved. The three-dimensional motion of the workpiece can improve the uniformity of the film. Fully automatic control to improve process stability. Can be plated TiN, TiC, TiCN, TiAlN, TiAlCN, TiCrN, TiCrCN, TiAlCrN, and multi-layer super hard coatings.

Cost savings

The coating tool is applied to significantly increase the cutting speed and the feed rate, and reduce the processing time and cost. Longer service life reduces the cost of replacing the tool.

HSC and dry processing

High speed machining (HSC) and dry machining of high temperature. Because the coating has excellent thermal stability, hardness and oxidation resistance, heat from debris away, will not cause a negative impact on the blade.

Hard machining

Hard and wear-resistant coating can be processed up to 63 HRC of hardened material. The tool that uses a specified blade, can be used for final machining of hard workpieces, thereby no subsequent grinding is required.

Materials difficult to be processed
Aluminium, titanium and magnesium alloy and high alloy steels are difficult to machine. Special coating with low friction coefficient and low adhesion tendency makes it easy to process this kind of materials.

Special tools
Customized coatings can improve the performance of special tools (e.g., fine tools).

Re-coating

If the re-grinding tool is recoated, their performance will be the same as the new coating tool, the overall service life will be longer. If you want to maintain the life and cutting parameters of the production line, it must be re-coated.

Heavy grinding

Re-grinding and re-coating process must be quickly and effectivel carried out. In order to ensure this property, Balzers has established cooperative relations with worldwide famous cutter mill manufacturers.
