Hard coating with excellent performance by vacuum arc ion plating, obtained by vacuum arc ion plating.
• The dynamic current regulator ensures the stability and distribution of the deposition process.
• Particularly suitable for arc cathode processing technology
• Various communication interfaces enable the power supply to integrate with other devices.
Features：
• Unique power and control design, high stability
• Integrated electronic ignition circuit and single ignition output terminal
• Fast DSP control, to ensure arc stability
• Wide range of current selection, supporting for a wide range of applications
• Voltage, current and power regulation synchronization
Customer benefit：
• Stable production process
• The adjustment of the arc ignition device is simplified, and the assembly time is shortened.
• Significantly improve production efficiency
• Single power input design, shorten the training and configuration time
• Shorten the adjusting time
Single power input design, shorten the training and configuration time
| Product | Power supply | Output | Output | Cooling method | Power |
| [kW] | Voltage | Current | [V] | ||
| [V] | [A] | ||||
| TruPlasma Arc 3150 | 9 | 60 | 150 | Air cooling | (±10%) 400 |
| TruPlasma Arc 3200 | 12 | 60 | 200 | Air cooling | (±10%) 400 |
Arc TruPlasma 3000 arc power series is a key component of arc cathode evaporation system, which is mainly used for hard coatings and decorative coatings. In addition, it is also suitable to be used in applications that have similar requirements for strong currents, such as ion implantation.
